How to Select Rock Drills

Pneumatic Rock Drills for B2B Project Matching

PerfoMax supplies handheld and air-leg pneumatic rock-drill configurations for mining, tunneling, quarry and construction rock work. This collection is the parent range for buyers comparing a complete drilling setup—not a promise that every model fits every hole, compressor or drill-steel system.

Air-Leg Rock Drills

For supported drilling, start with the Air-Leg Rock Drills collection, then compare the published YT24-series identification page, YT27 pneumatic air-leg rock drill, YT28 air-leg rock drill and YT29A air-leg rock drill. The YT24-series page remains a family-level reference until YT24C or TY24 is locked; supplier version, pressure-conditioned performance and delivered configuration remain controlled by the written quotation.

Handheld Pneumatic Rock Drills

Start with the Hand-Held Pneumatic Rock Drills collection when comparing the published Y24 handheld pneumatic rock drill and Y19A hand-held pneumatic rock drill as current hand-held-format references. Confirm the planned working direction, operating method, and any required or optional support equipment against the exact supplied model, manual, written quotation and site risk assessment. Final suitability still depends on rock condition, drilling direction, hole requirement, tooling interface and available air supply.

Active Pneumatic Rock Drill Model Comparison

Published ACTIVE model references; final values and suitability remain quotation-controlled.
Model Type Shank Hole range Weight Working pressure Typical application Product link
YT24-Series Air-leg H22 × 108 class; confirm suffix 34–42 mm class; confirm suffix Confirm by configuration Confirm by configuration Confirm by configuration View YT24-Series
YT27 Air-leg H22 × 108 34–42 / 34–45 mm; confirm in quotation 27 kg 0.4–0.63 MPa Confirm by configuration View YT27
YT28 Air-leg H22 × 108 34–42 mm 26 kg 0.50–0.63 MPa at the tool inlet (published performance reference); confirm the operating range for the supplied configuration Confirm by configuration View YT28
YT29A Air-leg H22 × 108 34–45 mm reference; confirm the supplied configuration Approx. 26.5 kg rock-drill reference; confirm the supplied configuration 0.4–0.63 MPa at tool inlet Confirm by configuration View YT29A
Y24 Handheld H22 × 108 34–42 mm 24 kg 0.4–0.63 MPa Confirm by configuration View Y24
Y19A Handheld H22 × 108 34–40 mm 19 kg 4–5 bar Confirm by configuration View Y19A

Match the Drill, Air Leg, Drill Steel and Bit as One System

For supported drilling, select the exact suffix on the FT160-series pneumatic air-leg page; similar suffix names do not prove interchangeability. Confirm the drill-side interface before choosing an H22 × 108 mm tapered drill rod, then use the Drill Bits collection to match taper, socket and target diameter. A shared shank label alone does not prove a complete compatible string.

For technical review, send the rock condition, target hole diameter and depth, drilling direction, available tool-inlet pressure and air-flow capacity, hose length and inner diameter, water supply, existing drill steel and bit connection, quantity, destination and inspection requirements. Where model-level sources conflict, the applicable value is confirmed in the order-specific quotation.

Additional Model Pages

Additional model pages are added to this collection only after the exact Product identity, signed technical fields, model-correct authorized images, public status and direct 200 URL have all passed. Draft, HOLD and forbidden objects are not linked from this public description.

Request a Configuration-Matched Quotation

If the model or connection is not yet clear, request a technical recommendation. The written quotation should identify the exact drill body, air-leg suffix where required, lubricator, rod and bit system, hoses, accessories, packing, quantity and destination instead of assuming a bundled scope.

Technical Guides for Rock Drills

Start with the guide that matches your current decision: system selection, compatibility, troubleshooting, or procurement.

APPLICATION-LED PRODUCT MATCHING

Match a Pneumatic Rock Drill as a Complete Drilling System

For B2B sourcing, the model name is only one input. Confirm the drilling direction, hole requirement, rock and fracture conditions, working-face air supply, air-leg requirement, H22 drill-steel interface and flushing arrangement before requesting a quotation.

Buying pathWhat must be confirmedRelevant PerfoMax page
Hand-held drillingWorking position, access, hole requirement, H22 × 108 interface and flushingY19A hand-held rock drill
Air-leg drillingRock drill model, air-leg suffix, face pressure and flow, hole and depth requirementYT28 · YT29A
Model confirmationExact nameplate, configuration, shank and supporting documentationYT24-series confirmation
Air-leg matchingRock drill model and exact FT160 suffix; do not select by family name aloneFT160-series air legs

Information to include in your RFQ

  • Rock type, fracture condition and drilling direction
  • Required hole diameter and depth
  • Compressor pressure and flow at the working face
  • Current shank, drill rod, bit and flushing arrangement
  • Model nameplate, quantity and destination country

Continue your selection

Underground mining drillingQuarry and blast-hole drillingAir-leg rock drill selection guide

Send the application, current equipment or interface, required size, quantity and destination. PerfoMax will use those inputs to review compatibility before the commercial quotation.
