Pneumatic Equipment
Component machining, model-specific assembly and the applicable functional check.
MANUFACTURING & SUPPLY
Manufacturing & Supply
Different drilling products need different manufacturing and control routes. The model, component, interface and order requirement determine the applicable sequence; every item returns to one packing and dispatch review.
01 / ORDER ROUTES
Different constructions need different manufacturing routes.
REQUIREMENT & ROUTE REVIEWProduct · interface · operating conditions · records
Rods & Interfaces
Incoming identity, long-stock preparation, straightness, passage and end review.
RELEASE REVIEW → PACKING → DISPATCH
02 / COMMON INPUT
Every route starts with the exact product and interface.
The order starts with product identity, interface, operating conditions and required records. Those inputs decide which route and control points apply.
PRODUCT / MODELAPPLICATIONINTERFACEQUANTITYDESTINATIONREQUIRED RECORDS
03 / ROUTE A
Pneumatic equipment: control the component, configuration and function chain.
The exact sequence is confirmed by model and component. Forming, heat treatment and other process steps are included where the component route requires them.
A1
Pneumatic-Component Machining
Applicable bodies and components are machined to the approved product specification.
A2
Model-Specific Assembly
Assembly follows the confirmed model, shank, inlet and component configuration.
A3
Applicable Functional Check
Operating checks are defined by product type, method, conditions and agreed coverage.
04 / ROUTE B
Rods and interfaces: the system determines the route.
Integral drill steel, tapered rods, threaded top-hammer systems and DTH pipe systems are separated before dimensions and interfaces are reviewed.
B1
Incoming Identity & Dimensions
Rod size, length and visible end form are reviewed against the approved requirement.
B2
Long-Stock Preparation
Long stock is prepared for the applicable rod or pipe route.
B3
Straightness Review
Straightness is checked for applicable rods or pipes using the specified method.
B4
Passage & End Review
Flushing passage and end condition are reviewed where applicable; the interface family is confirmed to the approved specification.
05 / ONE SHIPMENT REVIEW
Two product routes. Two packing forms. One complete-order check.
Before dispatch, review item identity, mating interfaces, quantities, inspection status, package marks, documents and the delivery route.
Boxed-Equipment Dispatch Path
Released equipment follows the agreed packing, marks and dispatch checklist.
Long-Item Dispatch Path
Released long items follow a load plan suited to length, bundle and handling requirements.
ITEM / MODEL / QUANTITYMATING INTERFACESINSPECTION STATUSPACKING MARKSDOCUMENTSDISPATCH ROUTE
06 / SPECIALIST SUPPLY
Specialist supply starts with the exact project requirement.
For PDC products, compressors, mining lamps, hydraulic equipment and larger drilling equipment, confirm the product, source, service responsibility, inspection, documents and delivery route before quotation.
