Direct answer: a rock drilling tool trial order should be approved only after the candidate tools are compared with the current accepted tools under matched field conditions. Use the same compatible drilling system, similar rock, hole geometry, operating window, inspection method and cost basis. Identify every tool, record every hole or shift, define safety stop rules before drilling, and judge the result with a balanced scorecard—not penetration rate alone.
The purpose is not to prove that a sample can drill one fast hole. It is to determine whether the proposed bit, rod, pipe, shank adapter, coupling or hammer can deliver repeatable productivity, acceptable wear and manageable risk in the buyer's real operation before a bulk purchase.
Rock Drilling Tool Trial Order: The Quick Decision Framework
| Gate | Question to answer | Minimum evidence | Do not approve when |
|---|---|---|---|
| Compatibility | Does the sample match the complete drilling system? | Confirmed dimensions, thread or shank, machine/hammer model, bit diameter and connection details | Fit is assumed from a trade name, photo or one nominal dimension |
| Test control | Can candidate and baseline results be compared fairly? | Matched rock domain, hole plan, operating window, operator instructions and time period | The candidate and baseline drilled different ground or under different settings without explanation |
| Traceability | Can every result be tied to a physical tool and supply lot? | Unique tool IDs, package/lot records, pre-use photos and drilling log | Tools were mixed, relabeled informally or removed without a failure record |
| Performance | Did the candidate deliver acceptable total value? | Meterage or holes, penetration, usable life, wear, downtime, failures and cost basis | Approval depends on one favorable metric or one short interval |
| Risk | Were abnormal events understood and contained? | Predefined stop rules, retained failed parts, photos and responsible technical review | A crack, thread problem, lost button, air leak or unexplained breakage is ignored |
A Trial Order Is Not the Same as Factory or Lot Inspection
Supplier qualification, first article inspection, receiving inspection and field testing answer different questions. A buyer can use all of them, but one does not replace the others.
- Supplier qualification asks whether the supplier's organization, process controls and evidence are credible enough to enter the approval process.
- First article inspection checks whether an initial production item conforms to the agreed drawing, specification and inspection plan before routine production.
- Receiving or AQL inspection samples a delivered lot for defined visual, dimensional or documentation defects.
- Controlled field trial asks whether traceable, conforming tools perform acceptably in the buyer's actual drilling system and ground conditions.
A field trial cannot rescue an incompatible tool or waive a drawing requirement. Conversely, a dimensionally conforming first article does not prove service life, penetration or cost per meter in a specific rock mass. Buyers should complete the specification and compatibility gates before exposing samples to production drilling.
Write the Test Plan Before the Samples Arrive
A useful trial plan names the decision, the comparison and the evidence in advance. If the team chooses the metrics after seeing results, it can unconsciously favor whichever tool performed better on the easiest holes.
Define the following:
- the tool family and exact candidate configuration;
- the approved current tool used as the baseline;
- the rig, rock drill or DTH hammer, compressor where relevant, and complete connection chain;
- hole diameter, depth range, direction and required hole quality;
- the rock domain, expected variability, water, fractures and abrasive intervals;
- the operating window taken from the equipment and tool manufacturers' instructions;
- which variables must remain constant and which may be adjusted under a written rule;
- inspection intervals, wear measurements and photo positions;
- stop rules for safety, abnormal wear, leakage, thread damage or failure;
- the scorecard and the person authorized to approve, extend or reject the trial.
Field-test results are specific to the actual drilling conditions. A headline life or penetration result from another mine is not a guaranteed result for different geology, equipment, air delivery or operating practice.
Control the Variables That Can Change the Answer
| Variable group | Hold constant or record | Why it matters |
|---|---|---|
| Ground | Rock type and domain, abrasiveness indicators, fractures, weathering, water and hole location | Strength and structure can change penetration, wear, flushing and failure mode |
| Hole plan | Diameter, depth, inclination, collar condition and required straightness | Longer or inclined holes can add bending, cleaning and handling effects |
| Machine and system | Rig, rock drill or hammer, shank/threads, rods or pipes, bit configuration and compressor | Energy, stiffness, air delivery and compatibility influence the entire result |
| Operating conditions | Percussion, feed, rotation, flushing, pressure/flow and lubrication as applicable | Different settings can make two identical tools appear to perform differently |
| People and timing | Operator, shift, warm-up condition, maintenance status and test sequence | Technique, machine condition and time-of-day effects can bias a short test |
| Tool condition | Initial dimensions, regrinding history, thread condition and unique ID | New candidate tools should not be compared with an undocumented or already damaged baseline |
Perfectly identical ground is rarely available. Reduce bias by drilling candidate and baseline tools in adjacent, mapped areas or by alternating them through a planned sequence. If the rock changes, record the boundary and analyze that interval separately. Do not drill all baseline holes in favorable ground and all candidate holes after the pattern reaches a fault, wet zone or abrasive band.
Choose a Representative Quantity, Not a Token Sample
There is no universal number of bits, rods or hammers that makes a trial valid. The quantity should be large enough to expose normal variation in the tool, ground, operators and production cycle, but small enough to control before bulk approval.
Base the trial quantity on:
- the consequence of failure and the value of the planned purchase;
- expected geology and operational variability;
- normal usable life and whether the trial can observe a complete life cycle;
- the number of rigs, shifts or operating crews represented;
- whether the candidate is a low-risk consumable or a critical pressure/energy-transfer component;
- how much within-lot variation the buyer needs to detect;
- whether repeat testing is possible before the commercial decision date.
One sample may reveal an obvious incompatibility, but it rarely establishes repeatability. At the other extreme, ordering a near-production quantity before acceptance criteria are agreed defeats the purpose of a controlled trial. Use a staged commercial release: engineering samples or a small traceable trial lot first, then a limited production order, then normal supply after the evidence is accepted.
Measure Productivity, Wear, Reliability and Cost Together
Rate of penetration is important, but it is only one component of drilling economics. Evaluate penetration, usable life, hole quality, change time, downtime and ownership cost as connected outcomes.
| Metric | How to record it | Interpretation caution |
|---|---|---|
| Meterage or holes completed | Record by unique tool ID and hole record | Separate full usable life from tools stopped early for schedule reasons |
| Penetration rate | Use comparable drilling intervals and a consistent time definition | Exclude or report setup, rod handling and delays separately |
| Usable life | Record the retirement reason and condition at removal | Do not treat a lost, damaged or untraceable tool as normal wear-out |
| Wear progression | Use defined inspection points, gauges and repeatable photos | Follow supplier/OEM wear and regrinding limits; do not invent a universal discard dimension |
| Failure mode | Preserve the part and document location, time, depth and operating context | Distinguish wear-out, misuse, incompatibility, ground event and manufacturing concern |
| Downtime | Log changeout, regrinding, stuck-tool recovery and unplanned inspection time | A faster-drilling tool can still lose value through frequent interruptions |
| Hole quality | Measure diameter, straightness or outcome required by the application | Fast penetration is not acceptable if the hole no longer meets the design |
| Cost per meter | Use landed tool cost plus agreed handling, service and downtime elements | Define the cost formula before comparing suppliers |
For a consistent commercial calculation, use the methodology in Rock Drilling Tool Cost per Meter. The final scorecard should show both the operating result and the assumptions behind the cost.
Create Tool-Level Traceability and Evidence
Assign each candidate and baseline tool a unique ID that survives cleaning, transport and shift changes. Link that ID to the purchase line, supplier lot, specification revision, pre-use inspection and every drilling record. Keep candidate and baseline markings visually distinct without damaging a functional surface.
A practical trial record includes:
- date, shift, operator and rig or machine ID;
- tool ID, supplier lot and complete drilling-system configuration;
- hole location, depth, diameter, angle and rock observations;
- operating settings or machine-log reference;
- start/stop times using a defined penetration-time method;
- meterage, hole count, changeouts and delays;
- wear measurements and photos from consistent angles;
- regrinding or servicing events;
- abnormal sound, vibration, leakage, flushing or thread behavior;
- retirement reason and disposition of the physical tool.
When a component fails abnormally, stop under the site procedure, isolate stored energy, preserve the failed pieces and record the surrounding conditions. Do not grind, weld, clean aggressively or discard the fracture surface before the responsible technical parties decide what examination is needed.
Replacement Pneumatic Rock Drill Trial: Approve the Whole Working System
A replacement pneumatic rock drill should not be approved because its model name appears equivalent or because it runs unloaded. Test the candidate as a complete working configuration: drill body, air leg where applicable, drill steel, bit, lubricator, hose, couplings and the actual compressed-air branch. The decision belongs to this trial-order page; direct model-to-model specification comparisons remain separate selection tasks.
| Trial gate | Record before or during drilling | Approve when | Hold or reject when |
|---|---|---|---|
| Identity and configuration | Candidate and baseline model/serial ID; supplied configuration; air-leg model; shank and steel; bit; lubricator; hose/coupling chain | Every interface is confirmed against controlled drawings, manuals or supplier data for the exact configuration | A family name, photograph or nominal size is being used as proof of interchangeability |
| Loaded air delivery | Pressure at the tool inlet while drilling; branch/manifold condition; hose ID and length; simultaneous tool demand; compressor operating state | The candidate can be assessed inside its documented operating envelope without depriving other tools of required air | Only receiver pressure or an unloaded gauge reading is available, or the branch cannot support the test safely |
| Lubrication and moisture control | Specified lubricant; lubricator setting/location; visible oil delivery check; separator/drain condition; ambient and air-line moisture observations | Both candidate and baseline receive controlled, documented air treatment | The test changes lubricant or moisture conditions between drills, or oil delivery cannot be confirmed |
| Matched drilling work | Rock domain; hole diameter/depth/angle; operator; collar condition; steel and bit condition; test sequence | Candidate and baseline drill comparable work, preferably in an interleaved sequence | Results come from different ground, different consumables or unexplained operating changes |
| Control and functional response | Start/stop behavior; percussion and rotation response; air-leg feed/control; flushing; leaks; abnormal noise, heat or vibration | Controls behave predictably and the configured system completes the required drilling cycle without an unresolved abnormal condition | There is unsafe response, leakage, repeated stalling, sticking, abnormal heating or an unexplained operating change |
| Productivity and support burden | Drilling time by comparable interval; holes/meters; delays; hose or steel changes; maintenance events; spare-part and training differences | The predefined productivity, hole-quality, maintainability and commercial gates are met together | One fast interval hides extra downtime, interface changes, support complexity or incomplete evidence |
| Evidence closeout | Signed record; photos; gauge/calibration reference; retained failed parts; deviation list; responsible approvers | Procurement, operations and maintenance can trace the result to one candidate configuration and defined application | Records are incomplete, results were averaged across configurations or a critical event remains unexplained |
Use a Four-Way Release Decision
- APPROVE FOR DEFINED APPLICATION: the exact tested configuration meets compatibility, safety, drilling, support and commercial gates. Approval does not automatically extend to another air leg, hose network, drill steel, bit or ground condition.
- CONDITIONAL PILOT: the result is promising but exposure is incomplete. State the single unresolved variable, limited quantity, operating boundary, owner and review date.
- HOLD FOR EVIDENCE: the comparison is not yet valid because a loaded inlet measurement, interface confirmation, matched baseline, traceability record or other required input is missing.
- REJECT FOR THIS APPLICATION: the candidate is incompatible, outside the agreed operating boundary, produces unacceptable hole or support outcomes, or presents an unresolved critical failure.
Copy-Ready Pneumatic Drill Trial Record
Record: site and heading/bench; date and shift; candidate and baseline model/serial IDs; approved configuration revision; air leg; drill steel/shank; bit; lubricator and lubricant; hose ID/length/couplings; compressor and active tool count; loaded tool-inlet pressure; rock and hole plan; operator; test sequence; holes/meters and drilling-time definition; downtime and maintenance events; control/rotation/percussion/feed/flushing observations; leaks, heat, noise and vibration observations; hole-quality result; required spares/training changes; deviations; retained evidence; final decision; decision owner; application boundary; review date.
Use supplier documentation and the site procedure for exact pressure, lubrication, inspection and stop limits. OSHA 1926.302 provides pneumatic-tool safety requirements, while ISO 11148-5 defines safety requirements for rotary percussive drills. Performance measurements should use a declared method; ISO 2787 is a reference for rotary and percussive pneumatic-tool performance testing. These sources do not supply universal acceptance limits for a particular PerfoMax model or site.
Use Predefined Pass, Conditional and Reject Rules
Approval thresholds must be specific to the application. A mine may value uninterrupted life and hole straightness more than peak speed; a contractor may prioritize predictable cost per meter and availability; a distributor may need evidence across several customer conditions. Do not copy numerical acceptance limits from an unrelated case study.
| Decision | Typical evidence pattern | Next action |
|---|---|---|
| Pass | Compatibility confirmed; required quality met; repeatable performance within the predefined commercial and risk limits; no unexplained critical failure | Approve the specified configuration and lot-control requirements for the next commercial stage |
| Conditional | Promising result but incomplete life observation, mixed geology, insufficient repetition or a correctable documentation gap | Extend the trial with one controlled change and a written decision deadline |
| Reject | Incompatibility, unsafe behavior, recurring abnormal failure, unacceptable hole quality, poor traceability or performance outside the agreed boundary | Quarantine remaining samples, document the reason and return to specification or supplier review |
Do not average away a serious failure. A candidate with favorable total meterage may still require rejection or investigation if it creates a pressure leak, repeated thread damage, unpredictable breakage or another unacceptable site hazard.
Common Trial-Order Mistakes
- Comparing different ground. Geological variation overwhelms a small performance difference.
- Changing several operating variables at once. The team cannot identify whether the tool or the setting produced the result.
- Using only penetration rate. Wear, downtime, hole quality and cost remain hidden.
- Using an unfair baseline. An undocumented worn tool makes the candidate look better; an unmatched premium configuration can make it look worse.
- Mixing sample lots. Results cannot be traced to the material or production batch actually offered.
- Defining acceptance after the trial. The decision becomes vulnerable to commercial pressure and selective interpretation.
- Continuing after a stop trigger. Production urgency does not override equipment manuals or site safety rules.
- Approving bulk supply from one favorable shift. Short results may not include normal rock and operating variation.
- Ignoring packaging and identification. A good tool is not commercially controllable if the buyer cannot maintain lot identity through receipt and storage.
Trial-Order RFQ Checklist
Include these items when requesting a sample or limited trial lot:
- application, site and target decision date;
- rig, rock drill or hammer make/model and complete connection chain;
- current approved tool and its specification as the baseline;
- candidate dimensions, material/grade identifiers and drawing revision to be confirmed;
- hole diameter, depth, angle, rock conditions and required hole quality;
- compressor pressure/flow, lubrication and flushing details where relevant;
- trial quantity and whether the buyer must observe a complete usable life;
- unique marking, lot traceability, packing and documentation requirements;
- pre-shipment measurements or first-article evidence required before field use;
- field metrics, inspection intervals, wear limits and stop rules;
- commercial treatment of unused, failed or nonconforming samples;
- technical contact and required response time for abnormal findings.
Use Rock Drilling Tool Supplier Qualification to set the wider approval process, and complete First Article Inspection for Rock Drilling Tools before treating field performance as permission to ignore dimensional or documentation requirements.
Frequently Asked Questions
How many rock drilling tools are needed for a valid trial?
There is no universal quantity. Use enough traceable tools to represent the relevant ground, operators and expected life variation, with a quantity proportional to failure consequence and purchase value. One tool can reveal a fit problem; it rarely proves repeatable performance.
Should the candidate and baseline drill on the same bench?
Prefer adjacent or interleaved holes in the same mapped rock domain when practical. If they cannot use matched ground, document the geological difference and avoid presenting the results as a direct supplier comparison.
What if the candidate penetrates faster but wears sooner?
Compare cost per meter, downtime, hole quality, changeout burden and risk under the predefined scorecard. Higher penetration may justify shorter life in one operation and fail commercially in another.
Can certificates replace a field trial?
No. Material, dimensional and inspection evidence confirms specified attributes; it does not reproduce the buyer's geology, machine condition, operator practice or production cycle. Certificates and field evidence are complementary.
When is a trial order ready for bulk approval?
When compatibility and traceability are confirmed, the predefined performance and hole-quality gates are met across representative conditions, and no critical failure remains unexplained. If exposure is incomplete, approve only the next limited stage rather than normal supply.
